AD ADUM2285 ADUM2285BRIZ Цифровые изоляторы

AD

ADUM2285BRIZ

ADUM2285 Лист данных

Категория продукта

Цифровые изоляторы 5kV RMS Dual CH Digital

приложение

General-purpose, high voltage, multichannel isolation

Medical equipment

Power supplies

RS-232/RS-422/RS-485 transceiver isolation

спецификация

High isolation voltage: 5000 V rms

Up to 100 Mbps data rate

Low propagation delay: 24 ns maximum

Low dynamic power consumption

Bidirectional communication

3 V to 5 V level translation

High temperature operation: 125°C

High common-mode transient immunity: >25 kV/μs

Default high output: ADuM2280/ADuM2281

Default low output: ADuM2285/ADuM2286

16-lead SOIC wide body enhanced creepage package

Safety and regulatory approvals (pending)

UL recognition: 5000 V rms for 1 minute per UL 1577

CSA Component Acceptance Notice #5A

IEC 60601-1: 250 V rms (reinforced)

IEC 60950-1: 400 V rms (reinforced)

VDE Certificate of Conformity

DIN V VDE V 0884-10 (VDE V 0884-10): 2006-12

VIORM = 846 V peak

Pin-compatible with ADuM220x and ADuM221x families
