TI DS100DF410 DS100DF410SQE Интерфейсные элементы Буферы и повторители сигналов

TI

DS100DF410SQE

DS100DF410 date sheet

Product category

Интерфейсные элементы - Буферы и повторители сигналов 10GbE Quad Channel Retimer

Application

Front Port SFF 8431 (SFP+) Optical and Direct Attach Copper

 Backplane Reach Extension, Data Retimer

• Ethernet: 10GbE, 1GbE

For other data rates and data transmission

protocols, other pin-compatible devices in the

retimer family can be used.

Description

• Each Channel Independently Locks to 10.3125 Gbps

• Lock Operation (typically under 15 ms)

Low Latency (~300 ps)

Adaptive Equalization up to 34 dB Boost at 5 GHz

Adjustable Transmit VOD: 600 to 1300 mVp-p

Adjustable Transmit De-emphasis to –12 dB

Typical Power Dissipation (EQ+DFE+CDR+DE): 180 mW/channel

Programmable Output Polarity Inversion

Input Signal Detection, CDR Lock Detection/Indicator

On-chip Eye Monitor (EOM), PRBS Generator

Single 2.5 V ±5% Power Supply

SMBus/EEPROM Configuration Modes

Operating Temperature Range of –40°C to 85°C

WQFN 48-Pin, 7 mm x 7 mm Package
