Azurewave AW NH580 AW-NH580 IEEE 802.11 b/g/n Беспроводная сеть

Производитель

Azurewave

Номер в каталоге производителя

AW-NH580

Категория продукта

Блютуз,GPS Модуль FM Combo

Лист данных

AW-NH580  Серия


Характеристики

Integrates ST-Ericsson solutions of ST-Ericsson CG2900 GPS/BT/FM SoC and

CW1100 Wi-Fi SoC

Depopulated 100-pin WLCSP 9.60 mm x 9.60 mm x 1.3 mm with 0.95 mm pitch

SDIO interfaces support for WLAN

High speed UART and PCM/I2S for Bluetooth, GPS and FM

Audio DSP: embedded BT wide band speech SBC codec, A2DP SBC stereo encoding

and L2CAP encapsulation to reduce host processing

Direct loop-through mode from FM Rx audio to BT A2DP

Flexible Power Supply(3.6V~4.8V)

Multiple power saving modes for low power consumption

Lead-free /Halogen Free Design

Power supply

–Integrated SMPS for direct battery connection

–Software adjustable output voltage to minimize power consumption

Clocks

 –Low power clock input at 32.768 kHz required
