TOSHIBA TC358767XBG Аппаратные драйверы и контроллеры дисплеев

Производитель

TOSHIBA

Номер в каталоге производителя

TC358767XBG

Категория продукта

Аппаратные драйверы и контроллеры дисплеев

Лист данных

TC358767 Серия


Характеристики

Translates MIPI DSI/DPI Link video stream from

Host to DisplayPort Link data to external display devices.

The inputs are driven by a DSI Host with 4-Data

Lanes, upto1 Gbps/lane or DPI Host with

16/18/24 bit interface upto154 MHz parallel clock.

Supports HDCP Digital Content Protection

version 1.3 (DisplayPort amendment Rev1.1).

Embeds audio information from the I2S port into

the DisplayPort data stream.

The output Interface consists of a DisplayPort Tx

with a 2-lane Main Link and AUX-Ch.

Register Configuration: From DSI link or I2C interface.

Interrupt to host to inform any error status or

status needing attention from Host.

Internal test pattern (color bar) generator for DP

o/p testing without any video (DSI/DPI) i/p.

Debug/Test Port: I2C Slave

Серия:    TPS61030

Входное напряжение:   1.8 V to 5.5 V

Нестабильность выходной нагрузки: 0.6 %

Минимальная рабочая температура:  - 40 C

Диапазон рабочих температур:   - 40 C to + 85 C

Упаковка:     Reel

• 96% Efficient Synchronous Boost Converter

With 1000-mA Output Current From 1.8-V Input

Device Quiescent Current: 20-µA (Typ)

Input Voltage Range: 1.8-V to 5.5-V

Fixed and Adjustable Output Voltage Options Up to 5.5-V

Power Save Mode for Improved Efficiency at Low Output Power

Low Battery Comparator

Low EMI-Converter (Integrated Antiringing Switch)

Load Disconnect During Shutdown

Over-Temperature Protection

Available in a Small 4 mm x 4 mm QFN-16 or in a TSSOP-16 Package

APPLICATIONS

All Single Cell Li or Dual Cell Battery

Operated Products as MP-3 Player, PDAs, and

Other Portable Equipment
