ATMEL ATMEGA8535-16JU 8-битные микроконтроллеры

ATMEL ATMEGA8535-16JU 8-битные микроконтроллеры

Особенности

High-performance, Low-power AVR® 8-bit Microcontroller

Advanced RISC Architecture

130 Powerful Instructions Most Single Clock Cycle Execution

32 x 8 General Purpose Working Registers

Fully Static Operation

Up to 16 MIPS Throughput at 16 MHz

On-chip 2-cycle Multiplier

Nonvolatile Program and Data Memories

8K Bytes of In-System Self-Programmable Flash

Endurance: 10,000 Write/Erase Cycles

Optional Boot Code Section with Independent Lock Bits

In-System Programming by On-chip Boot Program

True Read-While-Write Operation

512 Bytes EEPROM

Endurance: 100,000 Write/Erase Cycles

512 Bytes Internal SRAM

Programming Lock for Software Security

Peripheral Features

Two 8-bit Timer/Counters with Separate Prescalers and Compare Modes

One 16-bit Timer/Counter with Separate Prescaler, Compare Mode, and Capture

Mode

Real Time Counter with Separate Oscillator

Four PWM Channels

8-channel, 10-bit ADC

8 Single-ended Channels

7 Differential Channels for TQFP Package Only

2 Differential Channels with Programmable Gain at 1x, 10x, or 200x for TQFP

Package Only

Byte-oriented Two-wire Serial Interface

Programmable Serial USART

Master/Slave SPI Serial Interface

Programmable Watchdog Timer with Separate On-chip Oscillator

On-chip Analog Comparator

Special Microcontroller Features

Power-on Reset and Programmable Brown-out Detection

Internal Calibrated RC Oscillator

External and Internal Interrupt Sources

Six Sleep Modes: Idle, ADC Noise Reduction, Power-save, Power-down, Standby

and Extended Standby

I/O and Packages

32 Programmable I/O Lines

40-pin PDIP, 44-lead TQFP, 44-lead PLCC, and 44-pad QFN/MLF

Operating Voltages

2.7 - 5.5V for ATmega8535L

4.5 - 5.5V for ATmega8535

Speed Grades

0 - 8 MHz for ATmega8535L

0 - 16 MHz for ATmega8535

8-bit

Microcontroller

with 8K Bytes

In-System

Programmable

Flash

ATmega8535

ATmega8535L

Summary

 2502KS–AVR–10/06

Note: This is a summary document. A complete document

is available on our Web site at www.atmel.com.

2 ATmega8535(L)

2502KS–AVR–10/06

Pin Configurations Figure 1. Pinout AT
