LTM4625 LTM4625IY 20VIN, 5A Step-Down μModule Регулятор DC / DC

Особенности

Образ

ФУНКЦИИ

Complete Solutioi<1cm2 (Single-Sided PCB) or

0.5cm2 (Dual-Sided PCB)

Wide Input Voltage Range: 4V to 20V

Input Voltage Dowto 2.375V with External Bias

0.6V to 5.5V Output Voltage

5A DC Output Current

±1.5% Maximum Total DC Output Voltage Error

Over Line, Load and Temperature

Current Mode Control, Fast Transient Response

External Frequency Synchronization

Multiphase Parallel Current Sharing with

Multiple LTM4625s

Output Voltage Tracking

Selectable Discontinuous Mode

Power Good Indicator

Overvoltage, Overcurrent and Overtemperature

Protection

6.25mm x 6.25mm x 5.01mm BGA Package
