INOVA INAP125T24 цифровой автомобильный Pixel Link Передатчик

Приложения

Automotive Infotainment Displays

Head-Up Displays

Описание

• Up to 1 GBit/s Downstream Link

• Up to 62.5 MBit/s Upstream Link

• Low EMI, Two- or Four-Wire Full Duplex Link

• Accepts wide spread spectrum pixel clock

• +15 m Distance with low profile STP cables

• 10/12/18/24 bit pixel Interface

• Configurable sampling edge for pixel data

• DC-balanced line coding to support AC coupling

• Line Driver Current and Pre-Emphasis adjustable

• ISO10605 and IEC61000-4-2 compliant ESD protection

• Extended Temp. Range: -40 to +105°C
