ANAX IC Детали ANX6623 ANX6623AAQ TFT ЖК-дисплей Поставка

Приложения

 TFT ЖК-дисплей дляНоутбуки

таблетка Персональный компьютердисплей

портативный оборудование

Описание

FEATURES

2.5V to 5.5V input supply

Active-high Enable Control

Current-mode boost regulator

- 1.2MHz switching frequency

- Integrated 20V/1.8A 700mΩ FET

- Fast transient response to pulsed load

- High efficiency up to 90%

- Adjustable high-accuracy output voltage(±1%)

VGH positive charge pump

VGL negative charge pump

Integrated unity-gain VCOM buffer

- ±150mA output current limit

- 12V/us slew rate

- 12MHz Bandwidth

Low-voltage detection circuit

Soft-start and timed delay fault latch for all outputs

Thermal shutdown

Thin 3x3 mm 16-lead WQFN package

2-wire serial MPU interface (I2C compatible)

Single 1.8 V supply possible

1.8 V analog, 1.8 V PLL, 1.8 V digital, 1.8 V to 3.3 V I/O supply

−10°C to +70°C commercial temperature grade

−40°C to +85°C industrial/automotive qualified temperature grade

−40°C to +125°C temperature grade for automotive qualified 4 package types

64-lead, 10 mm × 10 mm, RoHS compliant LQFP

48-Lead, 7 mm × 7 mm, RoHS compliant LQFP

40-lead, 6 mm × 6 mm, RoHS compliant LFCSP

32-lead, 5 mm × 5 mm, RoHS compliant LFCSP
